TL25.60 Construction Telehandler

TL25.60 Construction Telehandler

Bobcat's Super compact Telehandler TL25.60 boasts the same spacious, comfortable workspace as larger models for all-day comfort. Thanks to the machine’s compact dimensions and excellent maneuverability, you can work in tight spots without compromising performance.

Request a Quote

TL25.60 Overview

TL25.60 components are well protected thanks to the robust build, while the box-welded frame makes the machine extra tough. The smooth hydrostatic transmission offers surgical precision and maximum uptime with a standard 3-year warranty (or 3000 hours) on the entire machine for peace of mind. Step into the cab, buckle your seatbelt, and start working. That's how easy it is to operate a Bobcat telehandler – thanks to the intuitive control layout, an all-in-one joystick, and automatic transmission.

TL25.60 Specifications

Compare

Key Specifications

TL25.60 Construction Telehandler
Rated Capacity
2500 kg
Lifting height
5.9 m
Rated power (ISO 14396)
54.6 kW
Max reach
3.3 m
Unladen weight
4308 kg

Key Specifications

TL25.60 Construction Telehandler
Rated Capacity
2500 kg
Lifting height
5.9 m
Rated power (ISO 14396)
54.6 kW
Max reach
3.3 m
Unladen weight
4308 kg

Dimensions

TL25.60 Construction Telehandler
Overall length (to forks tip)
5208.00 mm
Overall length (to forks face)
3989.00 mm
Overall length (to headstock pin)
3647.00 mm
Overall length (to front tyres 16.5")
3442.00 mm
Overall length (to front tyres 20")
3488.00 mm
Overall height with 16.5" tyres (with rotating beacon)
2085.00 mm
Overall height with 20" tyres (with rotating beacon)
2124.00 mm
Overall height with 16.5 tyres (with roof wiper)
1930.00 mm
Overall height with 20" tyres (with roof wiper)
1969.00 mm
Height back of the machine with 16.5" tyres
1340.00 mm
Height back of the machine with 20" tyres
1379.00 mm
Ground clearance with 16.5" tyres
250.00 mm
Ground clearance with 20" tyres
289.00 mm
Length - Front axle to forks face
1044.00 mm
Wheelbase
2360.00 mm
Length - Rear axle to machine rear
662.00 mm
Operator cab outside width
930.00 mm
Track width
1500.00 mm
Width over standard tyres
1832.00 mm
External turning radius with 16.5" tyres (at tyres)
3235.00 mm
External turning radius with 20" tyres (at tyres) with QT carriage
3729.00 mm
Internal turning radius with 16.5" tyres (cab)
1165.00 mm
Internal turning radius with 20" tyres (cab)
1676.00 mm
External turning radius with 16.5" tyres (with rigid forks spaced 1010 mm ext.) with BT
4271.00 mm
External turning radius with 20" tyres (with rigid forks spaced 1010 mm ext.) with BT
4593.00 mm
Carriage rotation angle
134.00 °

Performance

TL25.60 Construction Telehandler
Rated capacity
2500.00 kg
Capacity (at max. height on tyres)
1800.00 kg
Capacity at max. reach (16.5" tyres)
800.00 kg
Lifting height on tyres with BT carrier
5900.00 mm
Lifting height on tyres with QT carrier
5800.00 mm
Tilt Breakout force - ISO8313
3300.00 daN
Drawbar pull (16.5" tyres)
3350.00 daN
Drawbar pull (20" tyres)
2900.00 daN
Max. gradeability (16.5" tyres)
33.00 °
Max. reach (16.5" tyres QT)
3400.00 mm
Max. reach (16.5" tyres BT)
3300.00 mm
Reach at max height on tyres (16.5" tyres QT)
616.00 mm
Reach at max height on tyres (16.5" tyres BT)
539.00 mm

Cycle times

TL25.60 Construction Telehandler
Boom raising
5.60 s
Boom lowering
4.00 s
Boom extension
5.40 s
Boom retraction
3.40 s
Crowding
2.90 s
Dumping
2.70 s

Weights

TL25.60 Construction Telehandler
Unladen weight (16.5" tyres)
4308.00 kg
Unladen weight (20" tyres)
4413.00 kg

Engine

TL25.60 Construction Telehandler
Make / Model
Bobcat DM02
Fuel
DIESEL
Rated power @ 2400rpm (ISO 14396)
55.00 kW
Rated speed
2400.00 RPM
Maximum torque @ 1600 rpm
280.00 Nm
Number of cylinders
4.0
Displacement
2.39 L

Hydraulic system

TL25.60 Construction Telehandler
Pump type
Gear pump
Pump capacity
80.00 L/min
Relief valve pressure setting
250.00 bar
Control valve type
"Flow sharing valve Electro proportional control"

Drive system

TL25.60 Construction Telehandler
Transmission
Hydrostatic with electronic regulation
Main Drive
Hydrostatic motor

Traction

TL25.60 Construction Telehandler
Standard Tyres
CAMSO 12-16,5 SKS 532 12PR (R1 category)
Max speed - turtle mode (16.5"/20")
6,9 / 7,5 km/h
Max speed - rabbit mode (16.5"/20")
27,3 / 29,6 km/h

Brakes

TL25.60 Construction Telehandler
Engine Braking
Hydrostatic
Parking and Emergency brake
Passive brake
Service Brake
Oil immersed discs

Steering

TL25.60 Construction Telehandler
Steering Mode
2 wheel steering / 4 wheel steering / Crab-steering

Fluid Capacities

TL25.60 Construction Telehandler
Fuel tank
65.00 L
Hydraulic tank
42.00 L
Hydraulic system
70.00 L

Environmental

TL25.60 Construction Telehandler
Operator noise level (LpA) (EN 12053)
75.00 dB(A)
Level of acoustic power (LwA)
104.00 dB(A)
Whole body vibration (EN 13059)
1.20 ms2
