S100 Skid-Steer Loader

S100 Skid-Steer Loader

The Bobcat® S100 is the right size with enought lift capacity to help you in small spaces. It's a durable solution for all your industrial needs - and very comfortable for those daily jobs.

S100 Features

S100 Specifications

Compare

Key Specifications

Horsepower
24.8  hp
Rated Operating Capacity (ISO)
457  kg
Operating Weight
1860  kg

Key Specifications

Horsepower
24.8  hp
Rated Operating Capacity (ISO)
457  kg
Operating Weight
1860  kg

Model

Emissions Tier (EPA)
Tier 4
Loader Series
K-Series
Rated Operating Capacity (ROC) (ISO 14397-1)
457  kg
Tipping Load (ISO 14397-1)
914  kg
Height to Hinge Pin
2633  mm
Lift Arm Path
Radius

Size and Speed

Operating Weight
1860  kg
Bucket Width
1270  mm
Cab Height
1878  mm
Travel Speed – Low Range
8.2  km/h
Travel Speed – High Range (Optional 2-Speed Travel)
13.4  km/h

Engine

Horsepower
24.8  hp
Type
"Natural Aspirated"
Fuel Tank Capacity
45.0  L

Tires

Bobcat Standard Duty
-
Bobcat Heavy Duty
Standard
Bobcat Severe Duty
-
Bobcat Super Float
-

Control Options

Bobcat Standard (Foot Pedals/Steering Levers)
Standard
Selectable Joystick Control (SJC)
Optional
Radio Remote Control (SJC Required)
Optional

Machine Features

Air Ride Seat
-
Back-up Alarm & Horn
Standard
Bobcat Interlock Control System (BICSTM)
Standard
Cab with Heat
Optional
Cab with Heat & Air Conditioning
-
Deluxe Instrumentation (Includes Keyless Start)
-
Hydraulic Bucket Positioning
Optional
Front and Rear Work Lights
Standard
Radio
Optional
Ride Control
-
ROPS/FOPS Approved Cab Structure
Standard
Sound Reduction Package
Optional
2-Speed
Opt (w/SJC)

Features for Attachments

Attachment Control Kit
Optional
Bob-Tach Mounting System
Standard
Power Bob-Tach System
Optional
Fingertip Auxiliary Hydraulics Control
Opt (w/SJC)
Hydraulic System Pressure
207  Bar
Hydraulic Standard Flow
36.4  L/min
Hydraulic High Flow (Optional)
-
"Pressure Release Hydraulic Quick Couplers (Drain port)"
Opt (w/SJC)
