PA250V
Portable Air Compressor
PA250V Portable Air Compressor
The Bobcat® PA250V is a versatile workhorse suitable for a variety of jobsite applications, thanks to the FlexAir system that allows you to dial in your specific air power needs with the push of a button.
- FlexAir system provides tool-free adjustable air power
- Operational range from 250 cfm at 100 psi to 185 cfm at 175 psi
- Reliable tow-behind air compressor for versatile jobsites
PA250V Overview
The ultra-versatile and ruggedly reliable Bobcat PA250V portable air compressor is the machine you need at the jobsite when you’ve got multiple air power needs.
With the FlexAir System, you maintain complete control of both air pressure and airflow. From the control panel, you can dial in the exact combination of pressure and flow within the compressor’s operational range.
The PA250V can operate within a wide range of pressures and flows – from 250 cfm at 100 psi through 185 cfm at 175 psi – making it the perfect towable air compressor for jobs like sandblasting, construction or pneumatic tool operation. The FlexAir System gives you ultimate versatility to power a variety of jobsite applications all with a single machine.
The PA250V portable air compressor is powered by a Doosan D24 turbo diesel engine and engineered with emissions technology and zero-maintenance engine aftertreatment. The compact design and versatility of this model makes it a natural choice for a productive worksite.
PA250V Key Specifications
PA250V
Rated Operating Pressure
100 psig (6.9 bar)
Engine
PA250V
Engine Make
Doosan
Emissions Tier Level
Tier 4 Final (T4F)
Displacement
147 in³
System Voltage
12 V
Performance
PA250V
Rated Speed
2550 rpm
Idle Speed
1,400 rpm
Shipping Weight with Running Gear
2,353 lb
Operating Weight with Running Gear
2,594 lb
Shipping Weight without Running Gear
2,143 lb
Operating Weight without Running Gear
2,384 lb
Capacities
PA250V
Fuel Tank Capacity
34.5 gal
Dimensions
PA250V
Length with Running Gear
142.9 in
Width with Running Gear
68.5 in
Height with Running Gear
67.5 in
Track Width with Running Gear
60 in
Tire Size with Running Gear
15 in
Length without Running Gear
94.6 in
Width without Running Gear
49.3 in
Height without Running Gear
56.3 in
Compressor
PA250V
Rated Operating Pressure
100 psig (6.9 bar)
Pressure Range
80-175 psig (5.5-12.0 bar)
FlexAir Flow Range
249-185 cfm (7.0-5.2 m3/min.)
Air Discharge Outlet Size
0.75 in
PA185
Compare
PA185V
Compare
PA185VP
Compare
PA425V
Compare
PA450VP
Compare
PA750P
Compare
PA825V
Compare
PA915
Compare
PA1170P
Compare
PA1600VP (Cat Engine)
Compare
PA1600VP (Cummins Engine)
Compare
PA250V Key Specifications
PA250V
Rated Operating Pressure
100 psig (6.9 bar)
Engine
PA250V
Engine Make
Doosan
Emissions Tier Level
Tier 4 Final (T4F)
Displacement
147 in³
System Voltage
12 V
Performance
PA250V
Rated Speed
2550 rpm
Idle Speed
1,400 rpm
Shipping Weight with Running Gear
2,353 lb
Operating Weight with Running Gear
2,594 lb
Shipping Weight without Running Gear
2,143 lb
Operating Weight without Running Gear
2,384 lb
Capacities
PA250V
Fuel Tank Capacity
34.5 gal
Dimensions
PA250V
Length with Running Gear
142.9 in
Width with Running Gear
68.5 in
Height with Running Gear
67.5 in
Track Width with Running Gear
60 in
Tire Size with Running Gear
15 in
Length without Running Gear
94.6 in
Width without Running Gear
49.3 in
Height without Running Gear
56.3 in
Compressor
PA250V
Rated Operating Pressure
100 psig (6.9 bar)
Pressure Range
80-175 psig (5.5-12.0 bar)
FlexAir Flow Range
249-185 cfm (7.0-5.2 m3/min.)
Air Discharge Outlet Size
0.75 in
WARNING: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped), lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
